2-WAY TELESCOPE TRIPOD WITH 3D SAFETY ADAPTER FOR TRIMBLE

With the 2-way telescope tripod, you can position your Trimble laser scanner either up to 4.00m above or 4.50m below the ground.

The main pole of the manhole tripod with the 5/8" adapter can either be mounted upright or upside down in the tripod. For overhead scanning, simply mount the 3D safety adapter on the scanner; this will secure your valuable measurement equipment. By attaching extension rods, you can continuously expand the crank rod. This allows you to place your Trimble laser scanner in the best position for your measurement task.

Developed in Germany.


Designated use:

scanner usable over several heights . without assembly, disassembly and modification
enlargement of the possible scanner positions
safe overhead scanning
Product characteristics - 2-way telescope tripod:

tripod: 5/8" connection
indirect crank drive with enhanced gear unit
The crank drive can be operated by means of a hand crank or a screwdriver.
anti-twist geared column
additional leg braces for more stability
solid and quick locking mechanism
spirit level
set of shoes for tripod can be used on various surfaces
minimum effective depth: approx. -4.50m (177.2 in) underground
maximum useful height: approx. 4.00m (157.5 in)
transport length: approx. 1.30m (51.2 in)
weight: approx. 8.5kg
flat support plate with ø 110mm
During long-term usage, the scanner's weight should not be higher than 20kg.
4 prolongation tubes (each 1m (39.4 in)) in a robust transport case included
suited for all scanners with 5/8" connection (while scanning upright)
Please note: A suitable quick release is optionally available.
Product characteristics - 3D safety adapter:

The plate of the overhead adapter is firmly screwed to the original base plate of the scanner using the 5/8" star grip screw. The plate is additionally secured with the three M4 screws supplied.
The slot of the adapter is screwed on the tripod with a 5/8" connection.
The scanner with adapter plate can easily be put in the complement fixed at the tripod and secured.
5/8" female thread
weight: 1kg
dimensions: 10cm x 10cm x 10cm (3.94 in x 3.94 in x 3.94 in)
Compatible laser scanners:

Trimble X7
Trimble X9
Delivery contents:

1 aluminum telescope tripod with 5/8"
4 prolongation tubes in a robust transport case
1 crank for manual operation
1 bit for comfortable handling of the tripod by means of a screwdriver
special screwdriver for securing the single tube
1 3D overhead safety adapter for Trimble
Optional delivery contents:

Quick release for Trimble X7 and Trimble X9
tripod dolly
prolongation tube

Synonym: manhole tripod, chamber tripod, shaft tripod
