Terrestrial laser scanner with ultra-high accuracy and ingress protection for medium-range applications
FARO FocusS 150 is a 3D laser scanner of FARO's powerful FocusS series with ultra-high accuracy and ingress protection. Optimization of distance and angular accuracy as well as dual-axis compensator allows extremely accurate capturing of environments. Thanks to on-site compensation of FocusS, users can check and adjust scan data quality - whether in the office or on-site. Due to the integrated HDR camera, FocusS 150 can generate excellent detailed color images even under extreme brightness gradients.
Due to the extended temperature range from -20°C to +55°C, FARO FocusS can be used even in climatically challenging environments. Since the scanner has ingress protection IP54, integrated electronics are reliably protected from dust, debris and water splashes.
Product characteristics:
range: 0.6 to 150m
measuring speed: up to 976,000 points/second
multi sensor: GPS & GLONASS, compass, altimeter, dual axis compensator
distance accuracy: ± 1mm
on-site compensation
remote control via WLAN or mobile device
intuitive operation via touchscreen
small and compact (23 x 18.3 x 10.3cm)
light (4.2kg)
HDR photo overlay
HD photo resolution up to 165 megapixel color
integrated high-performance battery
data management on SD card
laser class 1
extended temperature range: -20° to +55° C
high scan data quality due to increased distance and angular accuracy
scanning in rough environments while providing protection from dust, debris ad water splashes (ingress protection IP54)
accessory bay
FARO FocusS 150 is ...
suited for indoor and outdoor scanning
even a perfect solution in climatically challenging environments
easy to use
a stand-alone solution
precise and fast
economical
