Laser Scanner Reference Sphere Set (Basic)

Our Reference Sphere Set "Basic" is designed for beginners and for occasional use. The surface is coated with a special paint; it resists normal stresses under normal use. The sphere is supplied with a magnetic holder and can, thus, be fixed easily on magnetic surfaces. Quality: Made in Germany.

Product attributes:

reference sphere:

Diameter Ø 145mm (5.7 in)
Spherical shape allows the highest possible scanning efficiency from various directions
it has been proven to be the most effective laser scanning target
special adapter (female thread M8) for Mini Prism (item no.: 030-90023)
Reference sphere is a hollow made of plastic with a distinctive surface to achieve excellent reflective properties
includes detachable magnet base
case dimensions: 575 x 470 x 205 mm (22.4 x 18.5 x 8.1 in)
case with precut foam insert for safe transport
reference sphere pedestal:

weight: 0.15kg
material: high-strength plastic
dimensions: diameter 16cm (6.29 in), height 2cm (0.79 in)
wear-resistant and non-corrosive material allows daily use and ensures durability
easily attach a reference sphere's magnet base to the precisely fitting metal disk of the reference sphere pedestal
safe positioning of the reference sphere due to the spikes attached to the base's bottom
Areas of application:

architecture, construction, and preservation of historic buildings and monuments
digital factory
aircraft construction
forensic
Compatible laser Scanners:

FARO Focus Premium
FARO Focus S 70
FARO Focus S 150
FARO Focus S 350
FARO Focus M 70
FARO Focus3D X 30
FARO Focus3D X 130
FARO Focus3D X 330
FARO Focus3D S 120
Trimble X7
Trimble TX5
Trimble TX8
Leica RTC360
Leica BLK360
Leica HDS 4400/ 6100
Leica ScanStation P20/ P30/ P40/ P50
Z+F IMAGER
GeoSLAM ZEB-HORIZON
GeoSLAM ZEB-REVO/ ZEB-REVO RT
GeoSLAM ZEB Discovery
Surphaser
Artec Ray
Teledyne Polaris
Riegl on request
Notes:

The reference sphere Basic is the perfect measurement sphere for scanning under normal conditions. We recommend using and storing these spheres only in the range from 0 to +50 degree. If the spheres are used at extremely cold ambient temperatures (< -5 degree), a damage of the painted surface might arise.
Do you need an overview on Laserscanning Europe's reference spheres? Have a look at our guide to reference spheres.

Do you want to know how to successfully use 3D reference stickers, reference spheres, and mini prisms? Check it out here:

>Laserscanning TV: Laserscanner Zubehör Video

Synonyms: reference ball, reference globe, target, scan sphere, reference target, control point, point of reference, reference point, reference sphere set, laser scanner target sphere set, laser scanner reference sphere set, laser scanner target sphere, laser scanner reference sphere, reference ball, target ball, ground control point, GCP

Product weight:7,50 Kg
