LIFT FOR LEVELING PLATFORM "LEVEL-LIFT ROOF"

Do you want to cover an even larger area when scanning? Then simply mount the leveling platform with laser scanner on this lift. With the lift for the leveling platform you can position your 3D laser scanner even higher so that, for example, no shadows are created when scanning balconies or other objects that are not visible from the ground. With the help of the lift you can reduce the number of stationings and thus save time.

The system consists of a pneumatically operated telescopic mast, an integrated compressor and an adjustable frame for mounting on the roof rack of any vehicle.

At the push of a button, the mast moves to the vertical position; The extensions are then extended to the maximum possible height.

Measuring principle:

The lift is used in combination with the leveling platform, a 3D laser scanner and a GPS receiver.

Mount the lift together with the leveling platform on the vehicle roof. Next, attach a 3D laser scanner to the platform and place a GPS receiver on the scanner. At the push of a button, the lift is brought into the vertical position and extended to the maximum. In this way the laser scanner reaches a very high position. You can now start scanning.

Move from one scanning position to another. At each scan position you have to stop the vehicle and level the leveling platform with the laser scanner at the push of a button. You can then scan the surroundings as usual.
Purpose of use:

Mounting the lift on the roof rack of a vehicle
Mounting the leveling platform on the lift
Many outdoor scanning positions must be managed; Scanning positions can be reached by motor vehicle
Scanning terrain, streets, topography, facades, etc.
Product features:

for higher positioning of the leveling platform
extendable telescopic mast
integrated compressor
Aluminum frame
maximum height of the extended mast: 3.00 m
Pole diameter: 115 mm
System weight: 55 kg
Maximum permitted payload: 45 kg
Dimensions of the closed system (l x w x h): 125 x 48 x 35 cm
Remote control to control the lift
Permitted temperature for operation: -15°C to +40°C
Permitted temperature for storage: -30°C to +50°C
Areas of application:

Architecture, construction and monument preservation
Mining and tunneling
Terrain surveying
Laser scanner compatibility:

The system is suitable for all 3D laser scanners with a 5/8 inch connection.
3D laser scanners with a 3/8-inch connection (e.g. Trimble TX5, FARO Focus3D) can be mounted using an adapter.
Scope of delivery:

1 lift for leveling platform (mast length: 3.00 m)
Aluminum frame and brackets for attachment to the vehicle's roof rack
1 remote control
1 power cable for vehicles
Adapter for the leveling platform
The lift system is compatible with the Level-Plane 21 leveling platform. This is not included in the delivery.


Lift for leveling platform - technical data sheet
